5/5M560JB
5/5M560JB
/
/

5/5M560JB

The 5/5M560JB is a factory-joined 5-band 5M banded belt assembly measuring 0.701" wide x 22.05" long, featuring oil and heat resistant rubber construction.

SKU: 1212549

$170.20

0 In Stock

In stock and ready to ship

Estimated delivery between June 16 and June 18.

Technical Specifications
Part Number 5/5M560JB
Top Width 0.701 in / 17.8 mm
Belt Depth 0.1575 in / 4.0 mm
Inside Length 21.85 in / 555.0 mm
Outside Length 22.05 in / 560.0 mm
Effective Length 22.05 in
Min Sheave Diameter 1.77 in / 45.0 mm
Ribs 5
Replaces These OEM Part Numbers (1)

This belt replaces the following OEM part numbers:

SIMPLICITY 157230
