5/BX112

Top Width: 3.4" (86.36mm)
Outside Length: 113.8" (2890.5mm)
Inside Length: 112" (2844.8mm)
Min Pulley Diameter: 4"
Profile: Cogged/Notched
Configuration: 5-Band Set

The 5/BX112 is a factory-joined 5-band BX banded belt assembly measuring 3.4" wide x 113.8" long, offering improved flexibility around smaller pulleys.

SKU: 1216551

$191.64

0 In Stock

In stock and ready to ship

Estimated delivery between June 19 and June 21.

Technical Specifications

Part Number	5/BX112
Top Width	3.4 in / 86.36 mm
Belt Depth	0.4375 in / 11.11 mm
Inside Length	112.0 in / 2844.8 mm
Outside Length	113.8 in / 2890.5 mm
Effective Length	113.4 in
Min Sheave Diameter	4.0 in / 101.6 mm
Ribs	5
Cogged	Yes
