11/BX96

Top Width: 7.516" (190.91mm)
Outside Length: 97.8" (2484.1mm)
Inside Length: 96" (2438.4mm)
Min Pulley Diameter: 4"
Profile: Cogged/Notched
Configuration: 11-Band Set

The 11/BX96 is a factory-joined 11-band BX banded belt assembly measuring 7.516" wide x 97.8" long, offering improved flexibility around smaller pulleys.

SKU: 1216346

$457.44

0 In Stock

In stock and ready to ship

Estimated delivery between June 18 and June 20.

Technical Specifications

Part Number	11/BX96
Top Width	7.516 in / 190.91 mm
Belt Depth	0.4375 in / 11.11 mm
Inside Length	96.0 in / 2438.4 mm
Outside Length	97.8 in / 2484.1 mm
Effective Length	97.4 in
Min Sheave Diameter	4.0 in / 101.6 mm
Ribs	11
Cogged	Yes
