18/A46

Top Width: 9.51" (241.55mm)
Outside Length: 47.3" (1201.4mm)
Inside Length: 46" (1168.4mm)
Min Pulley Diameter: 3"
Configuration: 18-Band Set

The 18/A46 is a factory-joined 18-band A banded belt assembly measuring 9.51" wide x 47.3" long, featuring oil and heat resistant rubber construction.

SKU: 1213657

$132.27

0 In Stock

In stock and ready to ship

Estimated delivery between June 23 and June 25.

Technical Specifications

Part Number	18/A46
Top Width	9.51 in / 241.55 mm
Belt Depth	0.3125 in / 7.94 mm
Inside Length	46.0 in / 1168.4 mm
Outside Length	47.3 in / 1201.4 mm
Effective Length	47.0 in
Min Sheave Diameter	3.0 in / 76.2 mm
Ribs	18
