17/A112

Top Width: 8.98" (228.09mm)
Outside Length: 113.3" (2877.8mm)
Inside Length: 112" (2844.8mm)
Min Pulley Diameter: 3"
Configuration: 17-Band Set

The 17/A112 is a factory-joined 17-band A banded belt assembly measuring 8.98" wide x 113.3" long, featuring oil and heat resistant rubber construction.

SKU: 1213646

$277.45

0 In Stock

In stock and ready to ship

Estimated delivery between June 23 and June 25.

Technical Specifications

Part Number	17/A112
Top Width	8.98 in / 228.09 mm
Belt Depth	0.3125 in / 7.94 mm
Inside Length	112.0 in / 2844.8 mm
Outside Length	113.3 in / 2877.8 mm
Effective Length	113.0 in
Min Sheave Diameter	3.0 in / 76.2 mm
Ribs	17
