13/A96

Top Width: 6.86" (174.24mm)
Outside Length: 97.3" (2471.4mm)
Inside Length: 96" (2438.4mm)
Min Pulley Diameter: 3"
Configuration: 13-Band Set

The 13/A96 is a factory-joined 13-band A banded belt assembly measuring 6.86" wide x 97.3" long, featuring oil and heat resistant rubber construction.

SKU: 1213466

$175.07

0 In Stock

In stock and ready to ship

Estimated delivery between June 22 and June 24.

Technical Specifications

Part Number	13/A96
Top Width	6.86 in / 174.24 mm
Belt Depth	0.3125 in / 7.94 mm
Inside Length	96.0 in / 2438.4 mm
Outside Length	97.3 in / 2471.4 mm
Effective Length	97.0 in
Min Sheave Diameter	3.0 in / 76.2 mm
Ribs	13
