The 11/A46 is a factory-joined 11-band A banded belt assembly measuring 5.8" wide x 47.3" long, featuring oil and heat resistant rubber construction.

SKU: 1213350

$67.32

0 In Stock

In stock and ready to ship

Estimated delivery between June 22 and June 24.

Technical Specifications
Part Number 11/A46
Top Width 5.8 in / 147.32 mm
Belt Depth 0.3125 in / 7.94 mm
Inside Length 46.0 in / 1168.4 mm
Outside Length 47.3 in / 1201.4 mm
Effective Length 47.0 in
Min Sheave Diameter 3.0 in / 76.2 mm
Ribs 11
