10/8V1600

Top Width: 10.27" (260.86mm)
Outside Length: 161" (4089.4mm)
Inside Length: 158.5" (4025.9mm)
Min Pulley Diameter: 12.5"
Configuration: 10-Band Set

The 10/8V1600 is a factory-joined 10-band 8V banded belt assembly measuring 10.27" wide x 161" long, featuring oil and heat resistant rubber construction.

SKU: 1224815

$1,159.22

0 In Stock

In stock and ready to ship

Estimated delivery between June 16 and June 18.

Technical Specifications

Part Number	10/8V1600
Top Width	10.27 in / 260.86 mm
Belt Depth	0.875 in / 22.22 mm
Inside Length	158.5 in / 4025.9 mm
Outside Length	161.0 in / 4089.4 mm
Effective Length	160.0 in
Min Sheave Diameter	12.5 in / 317.5 mm
Ribs	10
