5/7M1700JB

Top Width: 0.925" (23.5mm)
Outside Length: 66.93" (1700mm)
Inside Length: 66.73" (1695mm)
Min Pulley Diameter: 2.48"
Configuration: 5-Band Set

The 5/7M1700JB is a factory-joined 5-band 7M banded belt assembly measuring 0.925" wide x 66.93" long, featuring oil and heat resistant rubber construction.

SKU: 1212749

$342.96

0 In Stock

In stock and ready to ship

Estimated delivery between June 22 and June 24.

Technical Specifications

Part Number	5/7M1700JB
Top Width	0.925 in / 23.5 mm
Belt Depth	0.2165 in / 5.5 mm
Inside Length	66.73 in / 1695.0 mm
Outside Length	66.93 in / 1700.0 mm
Effective Length	66.93 in
Min Sheave Diameter	2.48 in / 63.0 mm
Ribs	5
