18/3V315

Top Width: 7.26" (184.4mm)
Outside Length: 31.8" (807.7mm)
Inside Length: 31" (787.4mm)
Min Pulley Diameter: 2.65"
Configuration: 18-Band Set

The 18/3V315 is a factory-joined 18-band 3V banded belt assembly measuring 7.26" wide x 31.8" long, featuring oil and heat resistant rubber construction.

SKU: 1223724

$138.54

0 In Stock

In stock and ready to ship

Estimated delivery between June 23 and June 25.

Technical Specifications

Part Number	18/3V315
Top Width	7.26 in / 184.4 mm
Belt Depth	0.3125 in / 7.94 mm
Inside Length	31.0 in / 787.4 mm
Outside Length	31.8 in / 807.7 mm
Effective Length	31.5 in
Min Sheave Diameter	2.65 in / 67.3 mm
Ribs	18
