9/B168

Top Width: 6.144" (156.06mm)
Outside Length: 169.8" (4312.9mm)
Inside Length: 168" (4267.2mm)
Min Pulley Diameter: 5.4"
Configuration: 9-Band Set

The 9/B168 is a factory-joined 9-band B banded belt assembly measuring 6.144" wide x 169.8" long, featuring oil and heat resistant rubber construction.

SKU: 1215591

$292.45

0 In Stock

In stock and ready to ship

Estimated delivery between June 25 and June 27.

Technical Specifications

Part Number	9/B168
Top Width	6.144 in / 156.06 mm
Belt Depth	0.4375 in / 11.11 mm
Inside Length	168.0 in / 4267.2 mm
Outside Length	169.8 in / 4312.9 mm
Effective Length	169.4 in
Min Sheave Diameter	5.4 in / 137.2 mm
Ribs	9
